Tumbler tilting lever engine control – Mercedes R107 C107 W108 W109 W111 W116 W126 C126 – M116 M117

Description

Rocker arm drawbar engine control – Mercedes R107 C107 W108 W109 W111 W116 W126 C126 – M116 M117

Tumbler, also known as tilting lever, rocker arm, Schwinghebel or towing lever mentioned, for various classic Mercedes models with the M116 and M117 V8 petrol engine.

The rocker arm forms an important part of the valve actuation system and transmits the movement of the camshaft to the valve. Wear on the contact surface of the rocker arm can lead to abnormal valve actuation and accelerated wear of the camshaft.

Price per piece

Suitable for Mercedes models

Mercedes R107 SL

• 350 SL – 107043 – M116.982 / M116.984 – 05.1971 to 02.1980
• 380 SL – 107045 – M116.960 / M116.962 – 09.1980 to 08.1985
• 420 SL – 107047 – M116.964 – 01.1986 to 08.1989
• 450 SL – 107044 – M117.982 / M117.985 – 10.1972 to 10.1980
• 500 SL – 107046 – M117.960 / M117.962 / M117.964 – 05.1980 to 08.1989

Mercedes C107 SLC

• 350 SLC – 107023 – M116.982 / M116.984 – 01.1972 to 02.1976
• 380 SLC – 107025 – M116.960 – 07.1980 to 08.1981
• 450 SLC – 107024 – M117.982 / M117.985 – 01.1973 to 08.1979
• 450 SLC 5.0 – 107026 – M117.960 – 06.1978 to 02.1980

Mercedes W108

• 280 SE 3.5 – 108057 – M116.980 – 03.1971 to 08.1972
• 280 SEL 3.5 – 108058 – M116.980 – 03.1971 to 08.1972

Mercedes W109

• 300 SEL 3.5 – 109056 – M116.981 – 01.1970 to 07.1972

Mercedes W111 Coupé

• 280 SE 3.5 Coupé – 111026 – M116.980 – 01.1969 to 12.1971

Mercedes W116 S-Class

• 350 SE – 116028 – M116.983 – 08.1972 to 02.1976
• 350 SEL – 116029 – M116.983 – 08.1972 to 02.1976
• 450 SE / SEL – 116032 – M117.983 / M117.986 – 01.1973 to 04.1980

Mercedes W126 S-Class

• 380 SE / SEL – 126032, 126033 – M116.961 / M116.963
• 420 SE / SEL – 126034, 126035 – M116.965 – 10.1985 to 12.1987
• 500 SE / SEL – 126036 – M117.961 / M117.963 – 12.1979 to 08.1985
• 560 SE / SEL – 126038, 126039 – M117.968 – 10.1985 to 06.1991

Mercedes C126 SEC

• 380 SEC – 126043 – M116.963 – 10.1981 to 07.1985
• 420 SEC – 126046 – M116.965 – 10.1985 to 12.1987
• 500 SEC – 126044 – M117.963 / M117.965 – 10.1981 to 06.1991
• 560 SEC – 126045 – M117.968 – 10.1985 to 12.1987

Suitable for Mercedes engines

• M116.980
• M116.981
• M116.982
• M116.983
• M116.984
• M116.960
• M116.961
• M116.962
• M116.963
• M116.964
• M116.965
• M117960
• M117961
• M117962
• M117963
• M117964
• M117965
• M117968
• M117982
• M117983
• M117985
• M117986

Specifications

1. Part: rocker arm, towing lever, rocker arm, Schwinghebel
2. OEM number: 1160551501
3. Alternative number: A1160551501
4. Application: valve actuation, engine control
5. Suitable for various Mercedes M116 and M117 V8 engines
6. Sales unit: per piece

Additional information

1. The rocker arm transfers the movement of the camshaft to the valve.
2. When replacing, carefully check the running surface of the rocker arm for wear and damage.
3. Also check the relevant camshaft lobe for wear, grooves, and damage.
4. A worn or damaged rocker arm can also damage the running surface of the camshaft.
5. When performing work on the valve actuation, we recommend carefully checking the other rocker arms and valve actuation components as well.

Always check before purchase and installation whether the part is suitable and equivalent based on photos, description, and specifications; installed or used parts cannot be returned.
